parallelogram Magnet Neodymium Iron Boron permanent from China manufacturer - Ningbo Xinqi Precision Magnetism Steel Co., Ltd

parallelogram Magnet Neodymium Iron Boron permanent

Price:	0.2 USD
Payment Terms:	T/T,L/C;Paypal
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 15*5*4mm

Production Capacity: 500,000pcs/month

Delivery Date: 25 days

Shape: Rhomboid

Composite: Neodymium Magnet

Material: Neodymium Iron Boron

Coating thickness: 10-20 um

Surface: Nickle

Lead time: 10-15days

Means of Transport: Ocean,Land,Air;Express Way

Packing: Small white box / Carton

Application: Motor Magnet

Type: Permanent

Brand Name: Xinqi

Grade: N/M/H/SH/UH/EH/AH

Place of origin: Ningbo

Certification: ISO/TS16949

Neodymium Iron Boron parallelogram Magnet
Nickle Plating
Material: N/M/H/SH/UH/EH/AH
Size:15*5*4mm
Grade: 45SH
Shape: Rhomboid
Used in motor

Neodymium Iron Boron parallelogram Magnet Nickle plate motor magnet

Xinqi's Principle of Quality:

Intensive management and super craftsmanship Lead to High quality, which together with credibility satisfies our customers.

Xinqi's Objectives:

1.The qualification rate of our finished products is no less than 98%

2.The customer satisfaction rate is no less than 95%

3.The zero kilometer breakdown rate of auto parts is less than 500 parts per million

Our advantage is:

1.Precision magnets.

2.Tight tolerance.

3.Difficult & irregular shape

Products:
Neodymium Iron Boron parallelogram Magnet Nickle plate motor magnet

Features:

1) Motor magnet, parallelogram shape
2) Size:15*5*4mm
3) Grade: 45SH
4) Coating: Nickle(≥15um) Excellent against Humidity and Salt spray
5) Magnetized through thickness

Packing:
Inner packing: small white box
Outer packing: Carton with OPP bag

Properties:

			(Hcb)		(Hcj)		(BH)max		Max Working
Grade	mT	kGs	kA/m	kOe	kA/m	kOe	kJ/m³	MGOe	Tempt(TW)℃
N35	1170-1220	11.7-12.2	≥868	≥10.9	≥955	≥12	263-287	33-36	80℃
N38	1220-1250	12.2-12.5	≥899	≥11.3			287-310	36-39
N40	1250-1280	12.5-12.8	≥907	≥11.4			302-326	38-41
N42	1280-1320	12.8-13.2	≥915	≥11.5			318-342	40-43
N45	1320-1380	13.2-13.8	≥923	≥11.6			342-366	43-46
N48	1380-1420	13.8-14.2	≥923	≥11.6			366-390	46-49
N50	1400-1450	14.0-14.5	≥796	≥10.0	≥876	≥11	382-406	48-51
N52	1430-1480	14.3-14.8	≥796	≥10.0	≥876	≥11	398-422	50-53	100℃
35M	1170-1220	11.7-12.2	≥868	≥10.9	≥1114	≥14	263-287	33-36
38M	1220-1250	12.2-12.5	≥899	≥11.3			287-310	36-39
40M	1250-1280	12.5-12.8	≥923	≥11.6			302-326	38-41
42M	1280-1320	12.8-13.2	≥955	≥12.0			318-342	40-43
45M	1320-1380	13.2-13.8	≥995	≥12.5			342-366	43-46
48M	1370-1430	13.7-14.3	≥1027	≥12.9			366-390	46-49
50M	1400-1450	14.0-14.5	≥1033	≥13.0			382-406	48-51	120℃
35H	1170-1220	11.7-12.2	≥868	≥10.9	≥1353	≥17	263-287	33-36
38H	1220-1250	12.2-12.5	≥899	≥11.3			287-310	36-39
40H	1250-1280	12.5-12.8	≥923	≥11.6			302-326	38-41
42H	1280-1320	12.8-13.2	≥955	≥12.0			318-342	40-43
45H	1320-1360	13.2-13.6	≥963	≥12.1			326-358	41-46
48H	1370-1430	13.7-14.3	≥995	≥12.5			366-390	46-49	150℃
35SH	1170-1220	11.7=12.2	≥876	≥11.0	≥1592	≥20	263-287	33-36
38SH	1220-1250	12.2=12.5	≥907	≥11.4			287-310	36-39
40SH	1250-1280	12.5=12.8	≥939	≥11.8			302-326	38-41
42SH	1280-1320	12.8=13.2	≥987	≥12.4			318-342	40-43
45SH	1320-1380	13.2=13.8	≥1003	≥12.6			342-366	43-46	180℃
28UH	1040-1080	10.4=10.8	≥764	≥9.6	≥1990	≥25	207-231	26-29
30UH	1080-1130	10.8=11.3	≥812	≥10.2			223-247	28-31
33UH	1130-1170	11.3=11.7	≥852	≥10.7			247-271	31-34
35UH	1170-1220	11.7=12.2	≥860	≥10.8			263-287	33-36
38UH	1220-1250	12.2=12.5	≥876	≥11.0			287-310	36-39
40UH	1250-1280	12.5=12.8	≥899	≥11.3			302-326	38-41	200℃
28EH	1040-1080	10.4=10.8	≥780	≥9.8	≥2388	≥30	207-231	26-29
30EH	1080-1130	10.8=11.3	≥812	≥10.2			223-247	28-31
33EH	1130-1170	11.3=11.7	≥876	≥11.0			247-271	31-34
35EH	1170-1220	11.7=12.2	≥876	≥11.0			263-287	33-36
38EH	1220-1250	12.2=12.5	≥899	≥11.3			287-310	36-39
28AH	1040-1080	10.4=10.8	≥787	≥9.9	≥2624	≥33	207-231	26-29	230℃
30AH	1080-1130	10.8=11.3	≥819	≥10.3			223-247	28-31
33AH	1130-1170	11.3=11.7	≥843	≥10.6			247-271	31-34

We are a professional NdFeB magnet manufacture for over 20 years experience.

Our advantage is:

1.Precision magnets.

2.Tight tolerance.

3.Difficult & irregular shape.

More important, we are manufacture, not trading company, we produce from raw material to processing, and we have complete set of quality checking equipment ( ICP, Laser Diffraction Particle Size Analyzer, HAST Tester, X-Ray Thickness Tester.......)

For quality system, we have passed ISO9001:2008 and TS16949.

We sincerely hoping to cooperate with you based on stable quality and competitive price. Please send us your inquiry and we will reply you asap.

Generally Information of Neodymium Rare Earth Magnet.

1. Material of Neodymium Rare Earth Magnet: Sintered Neodymium-Iron-Boron.
2. The Neodymium Rare Earth Magnet is the strongest power magnets in all of the permanent magnets.

3. Grade of Neodymium Rare Earth Magnet: N35 to N52; N33M to N50M; N35H to N48H, N35SH to N45SH; N28UH to N40UH, N28EH to N38EH and N28AH to N33AH.
4. Excellent strength value: the highest (BH)max reaches up to 53MGOe.
5. Extremely Resistance to demagnetization with Hcj, the intrinsic coercive force can be over 33,000Oe.
6. Moderate temperature stablity: under 80℃ for low Hcj NdFeB magnet and above 200 ℃ for high Hcj NdFeB magnet.
7. Coating: Effective Surface treatment to prevent corrosion, such as Nickel, Ni-Cu-Ni co, Zinc, gold, siliver, tin(Sn), epoxy, chemical, parylene, etc.
8.Shapes and sizes: various different sizes can be custom produced according to our customers' requests.
9. Application: Sensors, Motors, Rotors, Wind turbines/wind generators, Loudspeakers, Magnetic hooks & holder, Filters, Automobiles, etc.
